Drivetrain
| Transmission | manual |
| Clutch | Multi-plate with diaphragm spring in oil bath |
| Gearbox | 6-speed |
| Transmission Type | Chain (final drive) |
Suspension
| Front Suspension | Dual-bending valve 49 mm telescopic with aluminum fork triple clamps; dual rate spring; gaiter covers |
| Rear Suspension | Hidden, free piston, coil-over monoshock; 43mm stroke; cam-style preload adjustment |
| Front Travel | 5.5 in (140 mm) |
| Rear Travel | 4.1 in (104 mm) |
Brakes
| Front Braking System | Single disc. Optional ABS. 4-piston fixed. |
| Rear Braking System | Single disc. Optional ABS. 2-piston |
Tires
| Wheels | Black, Annihilator cast aluminum wheels. Dunlop Harley-Davidson Series, bias blackwal. |
| Front Tire | 100/90-B19 |
| Rear Tire | 150/80-B16 |
Dimensions
| Overall Vehicle Size | 91.3" length |
| Rake / Trail | 30° / 6" |
| Wheelbase | 64.2 in (1,630 mm) |
| Seat Height | 25.8 in (655 mm) |
| Ground Clearance | 4.9 in (125 mm) |
Capacities
| Hitch Type | Rear: Receiver |
| Fuel Capacity | 3.5 gal (13.2 L) |
| Seating Capacity | 0 |
Weights
| Dry Weight | 631 lbs (286.2 kg) |
Lights & Safety
| Warranty | 12-month limited warranty |
| Lighting | All LED. |
| Instrumentation | 2.14 inch LCD display with speedometer, gear, odometer, fuel level, clock, trip, range and tachometer indication |
What type of fuel does a 2022 Harley-Davidson Street Bob FXBB use?
A 2022 Harley-Davidson Street Bob FXBB uses Gasoline with fuel tank capacity up to 4 gallons.
What is the 2022 Harley-Davidson Street Bob FXBB fuel capacity?
A 2022 Harley-Davidson Street Bob FXBB has the fuel capacity of 4 gallons.
How much torque does a 2022 Harley-Davidson Street Bob FXBB have?
A 2022 Harley-Davidson Street Bob FXBB has 161 lb-ft torque.
What transmission does the 2022 Harley-Davidson Street Bob FXBB have?
The 2022 Harley-Davidson Street Bob FXBB has a manual transmission.
What engine does the 2022 Harley-Davidson Street Bob FXBB have?
The 2022 Harley-Davidson Street Bob FXBB is equipped with a 1868cc 4-stroke V2 engine.
What is the wheelbase of the 2022 Harley-Davidson Street Bob FXBB?
The 2022 Harley-Davidson Street Bob FXBB has a wheelbase of 64.2.
What type of engine does the 2022 Harley-Davidson Street Bob FXBB have?
The 2022 Harley-Davidson Street Bob FXBB is equipped with a 4-stroke engine.
How is the 2022 Harley-Davidson Street Bob FXBB cooled?
The 2022 Harley-Davidson Street Bob FXBB is cooled by Air.
What type of fuel system does the 2022 Harley-Davidson Street Bob FXBB have?
The 2022 Harley-Davidson Street Bob FXBB is equipped with an Injection. Electronic Sequential Port Fuel Injection (ESPFI) fuel system.
What type of starter does the 2022 Harley-Davidson Street Bob FXBB have?
The 2022 Harley-Davidson Street Bob FXBB is equipped with an Electric starter.
What is the 2022 Harley-Davidson Street Bob FXBB compression ratio?
The 2022 Harley-Davidson Street Bob FXBB has a compression ratio of 10.5:1.
What type of front brakes does the 2022 Harley-Davidson Street Bob FXBB have?
The 2022 Harley-Davidson Street Bob FXBB is equipped with Single disc. Optional ABS. 4-piston fixed. front brakes.
What type of rear brakes does the 2022 Harley-Davidson Street Bob FXBB have?
The 2022 Harley-Davidson Street Bob FXBB is equipped with Single disc. Optional ABS. 2-piston rear brakes.
